Regenerative Pumps
Reviving Energy, Powering Efficiency
REGENERATIVE WATER PUMPS
Latteys Self Priming Pumps are manufactured as per IS: 8472. These Self Priming Domestic Pumps are light in weight with rugged construction design and balanced parts which give noiseless operation for a longer duration. These pumps are available from 0.50 HP to 1.50 HP.
- The motor body is made from extruded aluminum and cast iron for better heat dissipation.
- Capacitor starts and runs motor with IP 44 protection.
- Pre-lubricated double-shielded ball bearings for a longer life.
- High quality carbon-ceramic mechanical seal for a longer life.
- The rotating parts of motor and pump are dynamically balanced to ensure minimum noise and vibration.
- Protective Enclosure - Totally Enclosed Fan Cooled motor (TEFC) type means no dust or moisture.
- Pump can operate in wide voltage range.
- High rise buildings
- Car washing
- Domestic & Hospitality Industry
- RO water treatments
- Solar Water Heater
Addition Information
Motor Body
Aluminium extruded.
Stator
Vacuum Impregnated and epoxy coated for corrosion resistance. Thick end laminations are provided to protect motor windings.
Rotor
Aluminium Die Cast rotor.
Windings
Enamelled copper insulated.
Impeller
High tensile bronze impeller.
Shaft
Stainless Steel of adequate diameter to ensure rigidity and ground to close tolerances.
Suction Casing/Flange
High graded Cast Iron.
-
Celino Regenerative PumpsHP Range 1-1.5 Discharge (lpm) 78 Up To Head Range (M) 15-19 Speed RPM 2800 -
Crystal Regenerative PumpsHP Range 0.5 Discharge (lpm) - Up To Head Range (M) - Speed RPM 2800 -
EVO (1.2) Regenerative PumpsHP Range 0.5 Discharge (lpm) 15 Up To Head Range (M) 13-20 Speed RPM 2800 -
LSPF(100,130,150) Regenerative PumpsHP Range 1-1.5 Discharge (lpm) Up To 21 Up To Head Range (M) 6-30 Speed RPM 2800 -
Mini Magic Regenerative PumpsHP Range 0.5 Discharge (lpm) 15 Up To Head Range (M) 12-20 Speed RPM 2800 -
Nexg (1,2) Regenerative PumpsHP Range Up To 1.2 Discharge (lpm) Up To 21 Up To Head Range (M) 5-55 Speed RPM 2800 -
Super Flow Regenerative PumpsHP Range 0.5 - 1 Discharge (lpm) 27 Up To Head Range (M) 12-20 Speed RPM 2800 -
Tejas Regenerative PumpsHP Range 1 Discharge (lpm) 35 Up To Head Range (M) 10-40 Speed RPM 2800 -
Shallow Well (LSJ 600,650,700,1000) Regenerative PumpsHP Range Up To 1 Discharge (lpm) Up To 85 Up To Head Range (M) 13-17 Speed RPM 2800 -
Pressure Booster (USP,80,52,53) Regenerative PumpsHP Range Up To 1 Discharge (lpm) Up To 54 Up To Head Range (M) 15-22 Speed RPM 2800 -
LSPH(80,90)Lsph 90 Alpha Regenerative PumpsHP Range 0.5 Discharge (lpm) 11.6 Up To Head Range (M) 6-24 Speed RPM 2800 -
LSPV(5,5Star) Regenerative PumpsHP Range 1 Discharge (lpm) 24 Up To Head Range (M) 12-20 Speed RPM 2800 -
Jalsuprime(1,2) Regenerative PumpsHP Range 1 Discharge (lpm) - Up To Head Range (M) 18-32 Speed RPM 2800
